5-2 RAID Enable in BIOS
1. Enter the BIOS setup by pressing <DEL> key when boot up.
2. Select the “Integrated Peripherals” from the “Main menu”, then select the “MCP
SATA Mode” menu and press <Enter> to go to the conguration items.
3. Enable RAID function and individual SATA port for hard drive or DVD connection.
4. Press <F10> to save the setting then PC will reboot itself.
5-3 Select a RAID Array for Use
When BIOS is restarted, it will display a message asking you to press [F10] key to
enter the main menu of MediaShield BIOS. Press [F10], the screen appears.
At the bottom of each screen displayed, there is one line listing each key’s function,
such as <Tab>, <Enter>, <ESC>...etc. It is helpful to make your choice easier.
MediaShield BIOS Jul 27 2007
- Dene a New Array -
RAID Mode: Mirrored Stripe Block: Optimal
Free Disks Array Disks
Port Disk Model Capacity Port Disk Model Capacity
[+] Add
[-] Del
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [Enter] Popup
0.0 WDC WD1200JD-9 111.79GB
0.2 Hitachi HDT725 232.88GB
0.1 HDS728080PLA38 76.69GB
0.3 ST3320620AS 298.09GB
Mirrored
Optimal
0.0 WDC WD1200JD-9 111.79GB
Phoenix - AwardBIOS CMOS Setup Utility
MCP SATA Mode
SATA Operation Mode [RAID] Item Help
SATA Pri-Master RAID [Enabled]
SATA Pri-Slave RAID [Enabled] Menu Level ►
SATA Sec-Master RAID [Enabled]
SATA Sec-Slave RAID [Enabled]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F7:Optimized Defaults
RAID
