Foxconn M7VMX series User Manual

1
2
1-1 Product Specications
CPU Support LGA775 socket Intel
®
CPU:
Core
TM
2 Quad / Core
TM
2 Extreme / Core
TM
2 Duo /
Pentium
®
Dual-Core / Celeron
®
processors
Future-proof supporting for 45nm processors
Front Side Bus 1333/1066/800 MH� FSB
Chipset NVIDIA GeForce 7050 / nForce 610i
Memory 2 x 240-pin DDR2 DIMM sockets
Support up to 4GB of system memory
Single channel DDR2 800(oc*)/667 MH� architecture (oc* : Overclocking)
Audio Realtek 6-channel audio chip (M7VMX / M7VMX-K)
Realtek 8-channel audio chip (M7VMX-S)
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF out
Support Jack-Sensing function
LAN Realtek 10/100 Mb/s LAN chip (M7VMX)
Realtek Gigabit LAN chip (M7VMX-K / M7VMX-S)
Expansion Slots 1 x PCI Express x16 slot
1 x PCI Express x1 slot
2 x PCI slots
Onboard Serial ATA 4 x SATA connectors
300MB/s data transfer rate
Support hot plug and NCQ (Native Command Queuing )
USB Support hot plug
Support up to 8 x USB 2.0 ports (4 rear panel ports, 2 onboard USB
headers supporting 4 extra ports)
Supports USB 2.0 protocol up to 480Mb/s
Internal Connectors 1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x Floppy disk drive connector
1 x IDE connector
4 x SATA connectors
2 x USB 2.0 connectors (supporting 4 x USB devices)
1 x CPU fan header (4-pin)
1 x System fan header (4-pin)
1 x Front Panel connector
1 x CD_IN connector
1 x Front Audio connector
1 x IrDA connector
1 x Chassis intrusion alarm header
1 x S/PDIF_OUT connector
1 x Bu��er (or Speaker connector)
