6. The screen displays a MIRRORED array of 232.88GB, which is the si�e of the smallest
hard disk. That is, 232.88GB.
If you want to build a new Operating System (such as Windows XP) in this RAID
system, please press [B] to select it as bootable.
You can then press [Ctrl]+[X] keys to exit the setup program, and restart your PC.
7. In above screen, you also can press <Enter> to know the detailed drive information of
this RAID system. Press [D] here allow you to delete previous settings, and go back
to the rst time when MediaShield was started.
MediaShield BIOS Jul 27 2007
- Array List -
[Ctrl-X] Exit [↑↓] Select [B] Set Bootable [N] New Array [ENTER] Detail
Boot Status Vendor Array Si�e
Healthy NVIDIA MIRROR 232.88G
Array 4 : NVIDIA MIRROR 76.69G
- Array Detail -
RAID Mode: Mirrored
Stripe Width : 1 Stripe Block: 64K
[R] Rebuild [D] Delete [C] Clear MBR [ENTER] Return
Port Index Disk Model Capacity
0.2 0 Hitachi HDT725025VLA380 232.88G
0.3 1 ST3320620AS 298.09G
