Franke A1000 Original Operating Instructions

Installation and technical data Page 20
Device type FCS4053
Milk container 12 l or 2 x 4.5 l
Electrical connection EU 220 – 240V1L N PE50/60Hz
SU12 FMCurrent consumption: 0.72A
Japan 100 V1L N PE50/60 Hz
SU12 FMCurrent consumption: 01.7 A
USA 100 – 127V1L N PE60 Hz
SU12 FM1.7 – 1.95 kW
SU12 FMCurrent consumption:
1.5 – 1.7 A
China 220V1L N PE50Hz
SU12 MSCurrent consumption: 0.8A
Electric cable 1800mm
Ambient conditions Humidity: max. 80%
Ambient temperature: 10 – 32°C
Coolant R134a/30 g
Climate class N (temperate climate)
Noise emission < 70dB (A)
Cooling temperature 2.0 - 5.0 °C
Empty weight (basic version) 25.7 kg
Width/Depth/Height 340mm/475mm/540mm
Under-counter refrigeration unit UT12 FM/UT12 FM Twin (optional) Payment system AC (option)
Flavor Station FS60 (option)
Weight 25.7 kg
Width/Depth/Height 320mm/467mm/547mm
Device type FCS4056
Electrical connection 85–264V1L N PE
Weight Approx. 18kg
Width/Depth/Height 200mm/451mm/542mm
Device type FCS4055
Capacity Up to 6 varieties of syrup
Bottle height Max. 330 mm
Electrical connection 230 V1L N PE50 W50/60 Hz 
Fuse: 10A
Electric cable 1800mm
Ambient conditions Humidity: max. 80 %
Temperature: 10 - 32°C
Weight Approx. 25kg
Width/Depth/Height 200 mm/452 mm/545 mm (540 mm without
key)
Refrigeration unit SU12 FM/SU12 FM Twin (optional)
Device type FCS4054
Capacity Up to 120 cups (depending on cup size)
Electrical connection 220-240V1L N PE120W50/60Hz 
Fuse: 10A
Weight Approx. 20kg
Width/Depth/Height 270 mm/475 mm/540 mm
Cup warmer CW (optional)

Franke A1000 Specifications

General

Model	A1000
Brand	Franke
Category	Coffee Maker
Daily Output	Up to 300 cups
Material	Stainless steel
Frequency	50/60 Hz
Dimensions	340 x 600 x 750 mm
Power Supply	220-240 V
Display	touchscreen
