14
03 / 2011
0.5 lb. [227 g]
1.0 lb. [454 g]
1.5 lb. [680 g]
0.69 lb. [312 g]
0.92 lb. [418 g]
1.38 lb. [625 g]
Last revised: Technical modifications excepted!
en
7 DISPENSING FROZEN FRIES
1 Remove Hash Brown Rack (If present/used)
Once the freezer has reached or -18° C or lower, open the freezer door and remove the optional
hash brown storage rack from the top of the hoppers.
(Tip: Use this optional rack to store bagged hash browns in the freezer during breakfast hours.)
2 Check the Hoppers
Check that the hoppers are empty. Discard any fries left in the hoppers.
3 Open Frozen Fries Box & Individual Bags
Open the frozen fries case and gently remove one of the bags. Pull the bag’s top seam apart
completely. Be careful not to break or crush the fries.
4 Fill Hoppers
Place the bag at the top of the hopper inside the freezer. NOTE: To minimize fry breakage, orient
bag so that most fries align parallel to the hopper rotor or perpendicular to the dispenser front.
Gently pour the fries from the bag into the hopper. Repeat this process until full. Each hopper
can hold up to 30-36 lbs. or 14-17 kg. of fries.
5 Power ON Lanes
Press and hold the Lane POWER touch pad for four seconds until the lights illuminate. Turn on
both lanes.
6 Load Size (SMALL is the default)
To change the dispense LOAD SIZE default, press left Action touch pad (under word: Small).
Display will scroll: Small-Medium-Large-Small, etc. Nominal or average load sizes are:
NOTE: The first load dispensed is always the default [Small] size.
* Standard Load Size [calibration] can be adjusted. See Service Manual Section D3 – Load Cell Calibration.
7 Dispense Fries
When the system is ready, indicated by the seven green LED lights in basket graphic
and word: Ready on Message Screen, place the empty basket in the loading chute
under the lane bin and push basket against the load activation bump switch. While
dispensing, the display screen will read: Filling and show the basket fill progress as a
growing horizontal bar.
LOAD SIZE* FOR US CALIBRATION EU/INT. CALIBRATION
SMALL [KLEIN]
MEDIUM [MITTEL]
LARGE [GROSS]
