INSTALLATION INSTRUCTIONS
Install Lamphead on Telescopic Pole
Lampheads and telescopic poles are shipped apart and need to be assembled
Note: The 512 telescopic pole must be installed before the lamphead is
attached if the small diameter hole is used. Refer to Install Models 510,
512 Top Mount Telescopic Poles.
1. Place the lamphead and the pole on a at surface.
2. Connect the lamphead wires to the pole wires. (Refer to Figure 1.)
a. Ensure that 3/8 inch of bare conductor shows at the end of each wire.
b. Insert the wires in the butt connectors and crimp.
For DC lights:
Connect black to black, white to red.
For AC lights:
Connect black to black, white to white, silver braid to green.
3. Ensure the crimps are tight. (Test by lightly tugging on the wires.)
4. Loop the excess wire in a zig-zag fashion to take up the slack.
Note: Ensure that the wires are not caught and squeezed by the lip of the
pole. If this happens the wire insulation may be cut and short the wires
to the pole.
5. Slide the lamphead onto the pole tucking the wires into the pole.
6. Apply thread lock and tighten the set screws to secure the lamphead on the pole.
(A medium strength locking compound like Loctite blue is recommended.)
