Part No. 90-0113-00
Fdmman2.p65 2/98
REMOTE CONTROL PANELS
Freedom Remote Control Panel
An optional remote control panel is
available. When the remote is used, the
power switch on the unit should be left OFF.
The remote control panel provides LED
bargraphs which show system status, battery
voltage and DC current in both inverter and
charger modes.
These bargraphs can also display dip
switch positions and shutdown conditions. Dip
switches allow the selection of battery type,
battery temperature, idle sensitivity, Power
Sharing, manual equalizing and auto/manual
charge modes. Refer to the Freedom Remote
Control Panel Addendum, pages 28-34, in
this manual for more information.
Link Instrumentation
More advanced optional remote control
panels are also available: the Link 1000, 2000
and 2000R.
Link 1000 controls the Freedom Inverter/
Charger and provides complete battery state-
of-charge information including DC voltage,
current, Amp-hours consumed, Time
Remaining and historical data for a single
battery bank.
The Link 2000 provides inverter/charger
control and complete battery state-of-charge
information for up to two battery banks.
The Link 2000R adds the ability to
control an engine-driven alternator. This
precision regulator transforms an alternator
into a 3-stage battery charging system.
If Link Instrumentation is used to control
the inverter/charger, refer to the Link Owner’s
Manual for setup and control information.
Refer to Installation Guide
for installation options.
6
