13. Attach the Pulse Crossbar (81) to the console
assemblywithsix#8x1/2"Screws(1).Start all
six Screws, and then tighten them.
 Firmlytightenthefour5/16"x5/8"Screws(11).
14.Firmlytightenthefour3/8"x23/4"Screws(22),
andthentightenthefour3/8"x11/4"Screws(3)
(only one side is shown).
Press the Left Base Cover (88) and the Right
Base Cover (not shown) onto the Base (29) until
they snap into place.
13
14
81
22
29
Console
Assembly
11
22
88
11
1
3
3
1
1
12. Set the console assembly on the Left and Right
Handrails (79, 83). Make sure that no wires
are pinched.InserttheexcessUprightWire(91)
behind the Console Frame (101).
Attach the console assembly to the brackets on
theHandrails(79,83)withthefour5/16"x5/8"
Screws (11) that you removed earlier. Do not
tighten the Screws yet.
12
83
Console
Assembly
11
11
91
79
