15
17. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill.
Note:Extrahardwaremaybeincluded.Keeptheincludedhexkeyinasecureplace;thehexkeyisusedto
adjust the walking belt (see pages 26 and 27).
16
16. Attach the upper end of the Storage Latch (54) to
theFrame(57)witha3/8"x2"Bolt(2)anda3/8"
Nut (9).
Lower the Frame (57) (see HOW TO LOWER
THE TREADMILL FOR USE on page 24).
57
54
9
2
15
15. Raise the Frame (57) to the position shown.
Have a second person hold the Frame until
step 15 is completed.
Orient the Storage Latch (54) so that the large
barrel and the latch knob are oriented as shown.
Remove any ties from the end of the Storage
Latch (54). Attach the lower end of the Storage
LatchtotheBase(29)witha3/8"x2"Bolt(2)
anda3/8"Nut(9).
57
54
29
2
9
Knob
Large
Barrel
