FreeWave Technologies Spread Spectrum Transceiver User Manual
900 MHz and 2.4 GHz
V5.0S
47
MultiPoint Communications
*CTS will be Solid Red with a solid link, as the link weakens the CTS light on the repeater and
slave wll begin to flash.
Table 16: LED Status in
Multipoint Mode
Master Slave Repeater
Condition CD TR CTS CD TR CTS CD TR CTS
Powered, disconnected
SR SD O SR O BR SR O BR
Repeater and slave
connected to master, no
data
SR SD O SG O SR* SG SD SR*
Repeater & slave
connected to master,
master sending data to
slave
SR SD O SG O SR* SG SD SR*
Repeater & slave
connected to master,
slave sending data to
master
SG-SR SD IF SG IF SR* SG SR SR*
Legend:
BR Blinking Red
FO Flashing Orange
IF Intermittent Flash Red
O Off
SD Solid Red, Dim
SG Solid Green
SR Solid Red, Bright
LED:
CD Carrier Detect LED
CTS Clear to Send LED
TR Transmit LED
