FreeWave Technologies Spread Spectrum Transceiver User Manual

900 MHz and 2.4 GHz

V5.0S

RS-422 & RS-485 Full Duplex pin-outs

Function Bare Board Pin Number DE-9 Pin Number

RX+ 7 3

RX- 9 7

TX+ 5 2

TX- 10 8

RS-485 Half Duplex pin-outs

Function Bare Board Pin Number DE-9 Pin Number

Wire to both pins for Buss + Short 5 & 7 Short 2 & 3

Wire to both pins for Buss - Short 9 & 10 Short 7 & 8

Table 20: RS-422 & RS 485

full duplex

Table 21: RS 485 half duplex
