FGR09xx FGR-115RE FGR-115RC FGR-115WC
Data port 10-pin PCB connector Ethernet RS232, DE9-F RS232, circular connector
Enclosure Bare board Extruded Aluminum Extruded Aluminum Extruded Aluminum
Waterproof
Dimensions 16 mm H x 62 mm W x 128
mm L
57 mm H x 74 mm W x 165
mm L
57 mm H x 74mm W x 165
mm L
60 mm H x 78 mm W x 165
mm L
Weight 441 grams 441 grams 496 grams
Power
Requirements
• 6 – 30 Vdc • 6 – 30 Vdc
• AC Wall Adapter
Provided
• May also be powered
through Pin 6 of DB9
connector.
• 6 – 30 Vdc
• AC Wall Adapter
Provided
• May also be powered
through Pin 6 of DB9
connector.
• 6 – 30 Vdc
• 6 foot data and power
pigtail provided.
• Data and power cable
also available
terminated with DB9
and power jack.
Antenna SMA female connector.
External antenna required
N type female connector.
External antenna required.
N type female connector.
External antenna required.
N type female connector.
External antenna required.
FCC Identifier KNY21161341911919 KNY21161341911919 KNY21161341911919 KNY21161341911919
DOC Identifier 2329 102 336A 2329 102 336A 2329 102 336A 2329 102 336A
