FreeWave Technologies Spread Spectrum Transceiver User Manual
900 MHz and 2.4 GHz
V5.0S
62
Board Level I-800X009 I-900X009
Data port 10-pin PCB connector RS232, DE9-F RS232, circular connector
Enclosure Bare board
Extruded Aluminum Extruded Aluminum
Waterproof
Dimensions 16 mm H x 62 mm W x 128
mm L
57 mm H x 74mm W x 165
mm L
60 mm H x 78 mm W x 165
mm L
Weight 441 grams 496 grams
Power
Requirements
• 9 – 30 Vdc
• 9 – 30 Vdc
• AC Wall Adapter
Provided
• May also be powered
through Pin 6 of DB9
connector.
• 9 – 30 Vdc
• 6 foot data and power
pigtail provided.
• Data and power cable
also available
terminated with DB9
and power jack.
Antenna SMA female connector.
External antenna required
N type female connector.
External antenna required.
N type female connector.
External antenna required.
