Fuse/Relay/Circuit Breaker
Identification
NOTE: The fuse/relay/circuit breaker panel
(
Fig. 2.13) is located under the glove box. De-
pending on vehicle options, fuse/relay/circuit
breaker locations may vary from those shown. Re-
fer to
Fig. 2.13 or Table 2.1 for the Fuse/Relay/
Circuit Breaker Identification information.
Fuse/Relay/Circuit Breaker Identification
Pos.
No.
Description
Part
Number
Rating
1 Daytime Running Lights 10A
2 Interior Lamps 10A
3 Turn Signal 25A
4 Customer Use (Battery) — —
5 Cigar Lighter 10A
6 Horn 10A
7
Trailer: Clearance Marker
Lamps
20A
8 Not Used — —
9
Headlamps
15A
CB
*
10 Not Used — —
11 Warning Lamps 10A
Fuse/Relay/Circuit Breaker Identification
Pos.
No.
Description
Part
Number
Rating
12 Stop Lamps 25A
13 Backup Lamps 10A
14 Washer Pump 10A
15 Fuel Shutoff 15A
16 Two-Speed Axle 25A
17 Wheel/Wheel and Diff Lock 10A
18 Exhaust Brake 10A
19 Customer Use (Start/Run) — —
20 Air Dryer 10A
21 Windshield Wipers
8.25A
CB
*
22 Blower Motor 10A
23 Radio 15A
24 Not Used — —
25 I/P Illumination Lamps 5A
26 Trailer: Tail/License Lamps 10A
27 Park and S/M Lamps 10A
28 Cab Roof Marker 10A
29 Not Used — —
30 Not Used — —
A Fuel Shutoff Relay
B Exterior Lighting Relay
