Frick QUANTUM HD - SIP Replacement Parts

QUANTUM™ LX/HD SYSTEM INTERFACE PANEL
INSTALLATION-OPERATION-MAINTENANCE
090.030-IOM (OCT 13)
Page 21
SIP REPLACEMENT PARTS
Frick
Number
SAP
Number
Description
Control Power
639A0185H10 483963 2-Pos. Selector Switch (Control Power)
639A0185H30 483966 Latch, 3 Across (Attaches contact block to switch mechanism)
639A0185H31 483967 Normally Open Contact Block (for Control Power Switch)
639A0206H05 484047 Circuit Breaker, 5 Amp.
Display Accessories
639D0199H01 703164 15” Color Display (Indoor)
649D6101G01 1032704 Touchscreen glass w/overlay of Frick logo
Flash Cards and Software
639A0290G07 1073320 Quantum™ SIP Program Flash Card (Version 2.00)
Harnesses
639B0116H01 677556 DC power-I/O Comms harness
639D0236H01 105758 SIP Harness, Ground
639B0118H01 670744 Display Harness
639B0126H01 884854 LED Inverter Harness
639D0191H03 696516 Harness Kit, Q5 to Interface Board Interconnect
Miscellaneous
333Q0001786 N/A Battery, 3V (located on Q5 board)
Power Supply
639B0115H02 642308 DC power supply – 12 VDC
Q5 Boards
649C1158G01 1034948 Q5 (Advantech Q5) (Does not include interconnect harness kit)
639B0116H01 677556 Interface Board (Does not include interconnect harness kit)
