Frick RWF II 100 User Manual

070.610-IOM (JUL 21)
Page 55
RWF II Rotary Screw Compressor Units
Maintenance
Figure 55: Compressor port locations - RWF II 316, 375 SS, 399, 472 SS
Port Thread size O-ring
SC-5 3/4-16 UNF-2B 980A0012K62
SC-6 9/16-18 UNF-2B 980A0012K60
SC-8 1
5
⁄16-12 UN-2B 980A0012K69
SC-9 9/16-18 UNF-2B 980A0012K60
SC-13 9/16-18 UNF-2B 980A0012K60
SC-14 9/16-18 UNF-2B 980A0012K60
SD-1 1
1
⁄16-12 UN-2B 980A0012K66
SL-1 1
5
⁄16-12 UN-2B 980A0012K69
SL-2 1
5
⁄16-12 UN-2B 980A0012K69
SM-1 1
5
⁄16-12 UN-2B 980A0012K69
