Frick RWF II 100 User Manual

070.610-IOM (JUL 21)
Page 72
RWF II Rotary Screw Compressor Units
Forms
Date: __________________________________________ Sales Order Number: ________________________________
End User: _______________________________________ Installing Contractor: ________________________________
Address: __________________________________________ Service Technician: __________________________________
___________________________________________________
___________________________________________________
Equipment ID (As in Microlog): ____________________________
Compressor Model Number: __________________________________
Compressor Serial Number: __________________________________
Unit Serial Number: _________________________________________
National Board Number: _____________________________________
Running Hours: _____________________________________________
Manufacturer and Size of Coupling: ____________________________
Motor Manufacturer: RAM ____________________________________
Motor Serial Number: ________________________________________
RPM: ________ Frame Size: ___________ H.P. __________
Refrigerant: ____________________________
Ambient Room Temperature: ____________°F
Operating Conditions:
Vibration data sheet
Suction Discharge Oil Separator Slide valve position
%
Press # Press # Press # Temperature °F V.I. Ratio
Temperature °F Temperature °F Temperature °F F.L.A. %
Compressor Inboard
(Coupling End)
Vertical Direction
____.____ IPS Overall
Compressor Inboard
(Coupling End Male)
Axial Direction
____.____ IPS Overall
Motor Inboard (Coupled End)
Horizontal _______ . ______ IPS Overall
Vertical _______ . ______ IPS Overall
Axial _______ . ______ IPS Overall
Compressor Outboard
(Nondrive End)
Vertical Direction
____.____ IPS Overall
Compressor Inboard
(Coupling End Female)
Axial Direction
____.____ IPS Overall
Motor Outboard (Noncoupled End)
Horizontal _______ . ______ IPS Overall
Vertical _______ . ______ IPS Overall
Axial _______ . ______ IPS Overall
