SGC/SGX ROTARY SCREW COMPRESSOR
INSTALLATION
Figure 18: Balance piston and squeeze lm damper locations (408 model)
INLET END
FEMALE SIDE
OUTLET END
FEMALE SIDE
OUTLET END
MALE SIDE
BALANCE
PISTON
INLET END
MALE SIDE
