PARTS CATALOG
9K Outdoor Condensor
Figure 901
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 67401110 1847918 - Fan Guard FPHFR09A3A 1
2 67401111 2103279 - Panel FPHFR09A3A 1
3 67401112 1203994 - Hex Nuts FPHFR09A3A 1
4 67400181 1556766 - Propeller Fan Blade FPHFR09A3A 1
5 67401113 1932167 - DC Motor FPHFR09A3A 1
6 67401114 2009048 - Motor Supporter FPHFR09A3A 1
7 67401115 1550928 ‑ Connecting Board FPHFR09A3A 1
8 67401116 1972348 ‑ Upper Board
FPHFR09A3A
1
9 67401117 1926335 ‑ Back Guard
FPHFR09A3A
1
10 67401118 1570578 ‑ Clapboard
FPHFR09A3A
1
11 67400283 1829624 ‑ PFC Inductance
FPHFR09A3A
1
12 67401119 1971738 ‑ Right Side Board
FPHFR09A3A
1
13 67401120 1863156 ‑ Wiring Distribution
Cover
FPHFR09A3A
1
14 67401121 1825563 ‑ Valve Cover
FPHFR09A3A
1
15 67400211 1546721 ‑ Sensor Mounting Plate
FPHFR09A3A
1
16 67401122 1972384 ‑ Condenser FPHFR09A3A 1
17 67401123 1924673 ‑ Four‑way Valve
FPHFR09A3A
1
18 67400193 1511783 ‑ Four‑way Valve Coil
FPHFR09A3A
1
19 67401124 1841376 ‑ Inverter Compressor
FPHFR09A3A
1
20 67401125 1511786 ‑ Electronic Expansion
Valve Coil
FPHFR09A3A 1
21 67401126 1559574 - Electronic Expansion
Valve
FPHFR09A3A 1
22 67401127 1555574 - Stop Valve FPHFR09A3A 1
23 67401128 1836723 - Inner Noise-
insulation Cotton
FPHFR09A3A 1
24 67401129 1566098 - Outer Noise-
insulation Cotton
FPHFR09A3A 1
25 67401130 1881249 - Bottom Noise-
insulation Cotton
FPHFR09A3A 1
26 67401131 1961881 - Base Holder FPHFR09A3A 1
27 67401132 1854766 - Tube Electric Heater FPHFR09A3A 1
28 67401133 1805723 - Fixing Clip FPHFR09A3A 1
29 67401134 1926233 - Electric Heating Belt FPHFR09A3A 1
30 67401135 1226723 - Compressor Hex Nuts FPHFR09A3A 1
31 67401136 1899954 - Electric Box Cover FPHFR09A3A 1
32 67401137 2084740 - Outdoor Main Control
Board Component
FPHFR09A3A 1
33 67401138 2089057 - Electric Box FPHFR09A3A 1
To Next Page
