Friedrich FPHFR9A3A - Product Dimensions: 9 K and 12 K Cassette

15 PB
SPECIFICATIONS
Product Dimensions: 9k and 12k Cassette
2-1/16(52)
2-7/16
(62)
22-7/16(570)
24-7/16(620)
24-7/16(620)
2(51)
3-11/16
(93)
12(305)
10-13/16(275)
12-11/16(323)
24-7/16(620)
20-7/8(530)
20-1/4(515)
24-7/16(620)
22-5 /8~23-1/4(575~590)
22-5/8~23-1/4(575~590)
5-7/16
(138)
5-1/16 (128)
1-5/8
(41)
(131)
3-1/8
(79)
5-3/16
8-7/16 (215)
1-7/8(48)
Unit: Inches “ (mm)
Figure 205
