Friedrich FPWC1 Service & Parts Manual

11 PB
SPECIFICATIONS
Product Specifications Single-Zone-Cassette
PERFORMANCE RATINGS 9k 12k 18k 24k 36k
INDOOR MODEL
FPHFC09A3A
FPHFC09A3B
Wi‑Fi"
FPHFC12A3A
FPHFC12A3B
Wi‑Fi"
FPHFC18A3A
FPHFC18A3B
Wi‑Fi"
FPHFC24A3A
FPHFC24A3B
Wi‑Fi"
FPHSC36A3B
Wi‑Fi
OUTDOOR MODEL FPHFR09A3A FPHFR12A3A FPHFR18A3A FPHFR24A3A FPHFR36A3A
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu 9000 12000 18000 24000 36000
CAPACITY COOLING (MIN~MAX) Btu 4850‑11600 5800‑13100 8000‑19200 8600‑25200 12600‑36800
CAPACITY HEATING @470F
(RATED)
Btu 9000 12000 11942 24000 42600
CAPACITY HEATING @170F
(RATED)
Btu 5120 6800 7500 19600 27300
CAPACITY HEATING (MIN~MAX) Btu 4340‑12280 6000‑14400 7000‑21200 7600‑28400 15000‑42600
SENSIBLE HEAT RATIO 76% 77% 76% 76% 79%
COP (@47°F) 4.00 3.80 3.90 3.61 3.31
SEER 18 19 19 19 19.5
EER 12.5 12.5 12.7 12.5 10.6
HSPF 10.00 10.00 10.00 10.00 10.50
MOISTURE REMOVAL Pts/h 2 3 5 5.1 7.61
AIRFLOW (LOW, MED, HIGH ) CFM 235/285/309 235/294/353 380/457/588 400/530/647 676/794/941
SOUND RATING ‑ INDOOR H/M/L dB(A) 40/33/28 35/32/29 38/35/33 43/39/36 49/43/39
SOUND RATING ‑ OUTDOOR dB(A) 52 54 68 54 61
OPERATING RANGE (COOLING) °F 5‑118 5‑118 5‑118 ‑4‑118 ‑4‑118
OPERATING RANGE (HEATING) °F ‑4‑75 ‑4‑75 ‑4‑75 ‑4‑75 ‑4‑75
ELECTRICAL DATA
POWER SOURCE V, Ø, Hz 208‑230/60/1 208‑230/60/1 208‑230/60/1 208‑230/60/1 208‑230/60/1
POWER AND COMMUNICATION
CABLE
TYPE
14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
MINIMUM AMPACITY A 23 23 23 23 27
COOLING WATTS W 720 960 1420 1920 3380
COOLING AMPS A 3.6 4.3 6.3 8.6 14.6
HEATING AMPS A 3.5 4.1 6.5 8.7 14.0
MAX. TD FUSE/BREAKER A 20 30 30 30 50
REFRIGERATION SYSTEM
REFRIGERANT R410a R410a R410a R410a R410a
COMPRESSOR TYPE Rotary Rotary Rotary Rotary Rotary
CONNECTIONS Flare Flare Flare Flare Flare
LIQUID LINE O.D. in 1/4 1/4 1/4 3/8 3/8
SUCTION LINE O.D. in 3/8 3/8 1/2 5/8 3/4
FACTORY PRECHARGE ft 25 25 25 25 25
REFRIGERANT CHARGE oz 33.5 45.9 56.5 75.3 111
MIN./MAX. LINE LENGTH ft 10‑82 10‑82 10‑98 25‑164 25‑164
MAX. HEIGHT DIFFERENCE ft 33 49 49 98 98
Figure 201

Friedrich FPWC1 Specifications
