SPECIFICATIONS
Product Specifications Single-Zone Concealed Ducted
PERFORMANCE RATINGS 9k 12k 18k 24k 36k
INDOOR MODEL FPHFD09A3A FPHFD12A3A FPHFD18A3A FPHFD24A3A FPHSD36A3A
OUTDOOR MODEL FPHFR09A3A FPHFR12A3A FPHFR18A3A FPHFR24A3A FPHFR36A3A
SPECIFICATIONS
CAPACITY COOLING (RATED) Btu 9000 12000 18000 24000 36000
CAPACITY COOLING (MIN~MAX) Btu 4850‑11600 5800‑13100 8000‑19200 8600‑25200 12600‑36800
CAPACITY HEATING @470F
(RATED)
Btu 9000 12000 18000 24000 36000
CAPACITY HEATING @170F
(RATED)
Btu 6200 8200 14700 19600 22000
CAPACITY HEATING (MIN~MAX) Btu 4340‑12280 6000‑14400 7000‑21200 7600‑28400 15000‑42600
SENSIBLE HEAT RATIO 76% 76% 76% 76% 76%
COP (@47°F) 3.2 3.2 3.4 3.6 3
SEER 17 19 19 18 18
EER 12 11 12.2 12.5 10.9
HSPF 10.00 10.00 10.00 10.00 9.50
MOISTURE REMOVAL Pts/h 2 3 5 5.1 7.61
AIRFLOW (LOW, MED, HIGH ) CFM 235/285/309 235/285/338 370/440/529 501/574/647 618/735/853
SOUND RATING ‑ INDOOR H/M/L dB(A) 29/27/26 36/33/30 38/35/33 38/36/34 49/43/39
SOUND RATING ‑ OUTDOOR dB(A) 52 54 68 54 61
OPERATING RANGE (COOLING) °F 5‑118 5‑118 5‑118 ‑4‑118 ‑4‑118
OPERATING RANGE (HEATING) °F ‑4‑75 ‑4‑75 ‑4‑75 ‑4‑75 ‑4.75
ELECTRICAL DATA
POWER SOURCE V, Ø, Hz 208‑230/60/1 208‑230/60/1 208‑230/60/1 208‑230/60/1 208‑230/60/1
POWER AND COMMUNICATION
CABLE
TYPE
14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
14/4 AWG
600V THHN
MINIMUM AMPACITY A 23.0 23.0 23.0 23.0 4.6
COOLING WATTS W 750 1091 1610 2200 3300
COOLING AMPS A 3.7 4.8 7.0 8.6 14.4
HEATING AMPS A 4.1 4.8 7.3 8.7 15.2
MAX. TD FUSE/BREAKER A 20 30 30 30 50
REFRIGERATION SYSTEM
REFRIGERANT R410a R410a R410a R410a R410a
COMPRESSOR TYPE Rotary Rotary Rotary Rotary Rotary
CONNECTIONS Flare Flare Flare Flare Flare
LIQUID LINE O.D. in 1/4 1/4 1/4 3/8 3/8
SUCTION LINE O.D. in 3/8 3/8 1/2 5/8 3/4
FACTORY PRECHARGE ft 25 25 25 25 25
REFRIGERANT CHARGE oz 33.5 45.9 56.5 75.3 111
MIN./MAX. LINE LENGTH ft 10‑82 10‑82 10‑98 25‑164 25‑164
MAX. HEIGHT DIFFERENCE ft 33 49 49 98 98
Figure 202
