Friedrich FPWC1 - Capacity Characteristics Chart; Single Zone Ducted

23 PB
Cooling Capacity Table
Model
(Btu/h)
Outdoor
Air Temp.
(°F D B )
Indoor Air Temp. °F DB / °F WB
68 / 57 73 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
18K
5 17.83 14.28 0.67 18.94 15.08 0.90 20.05 15.53 0.98 20.84 14.91 0.99 22.26 15.04 0.99 23.36 15.32 0.99
10 17.81 14.39 0.68 18.91 15.20 0.93 20.02 15.64 1.00 20.81 15.02 1.02 22.23 15.15 1.02 23.33 15.44 1.02
15 17.78 14.49 0.70 18.89 15.31 0.95 19.99 15.75 1.04 20.78 15.13 1.04 22.19 15.26 1.05 23.30 15.55 1.04
20 17.75 14.59 0.72 18.86 15.41 0.98 19.96 15.86 1.06 20.75 15.24 1.08 22.16 15.37 1.08 23.27 15.66 1.08
25 17.73 14.69 0.74 18.83 15.53 1.00 19.93 15.98 1.09 20.72 15.35 1.10 22.13 15.47 1.10 23.24 15.77 1.10
30 17.70 14.80 0.76 18.80 15.63 1.03 19.90 16.09 1.11 20.69 15.45 1.13 22.10 15.59 1.14 23.20 15.88 1.13
35 17.68 14.90 0.78 18.77 15.74 1.05 19.88 16.20 1.14 20.66 15.56 1.16 22.07 15.69 1.16 23.17 15.99 1.16
40 17.65 15.00 0.79 18.75 15.85 1.08 1 9.85 16.31 1.17 20.63 15.67 1.19 22.04 15.80 1.19 23.13 16.10 1.19
45 17.63 15.11 0.82 18.72 15.95 1.10 19.82 16.43 1.19 20.60 15.77 1.21 22.01 15.91 1.22 23.10 16.21 1.21
50 17.60 15.20 0.84 18.69 16.06 1.13 19.79 16.53 1.22 20.57 15.88 1.24 21.98 16.01 1.24 23.06 16.31 1.24
55 17.57 15.31 0.85 18.67 16.17 1.15 19.76 16.64 1.25 20.54 15.98 1.27 21.94 16.12 1.27 23.03 16.43 1.27
60 17.55 15.41 0.87 18.64 16.28 1.18 19.73 16.76 1.28 20.51 16.09 1.29 21.91 16.22 1.30 23.00 16.53 1.29
65 17.52 15.50 0.89 18.61 16.38 1.20 19.70 16.86 1.30 20.48 16.19 1.33 21.88 16.33 1.33 22.97 16.64 1.33
70 17.50 15.61 0.91 18.59 16.49 1.23 19.67 16.97 1.34 20.45 16.30 1.35 21.85 16.43 1.35 22.93 16.75 1.35
75 17.08 15.35 0.97 18.16 16.24 1.27 19.25 16.73 1.37 20.03 16.08 1.39 21.41 16.24 1.40 22.49 16.56 1.41
80 16.66 15.08 1.03 17.74 15.98 1.31 18.82 16.49 1.40 19.60 15.86 1.43 20.98 16.04 1.45 22.07 16.37 1.47
85 16.24 14.81 1.17 17.32 15.71 1.42 18.40 16.23 1.51 19.18 15.62 1.54 20.55 15.82 1.56 21.63 16.16 1.59
90 15.82 14.53 1.30 16.90 15.44 1.54 17.97 15.97 1.61 18.75 15.38 1.64 20.12 15.59 1.67 21.20 15.95 1.70
95 15.37 14.38 1.44 16.44 15.30 1.64 17.51 15.85 1.70 18.00 15.05 1.67 19.65 15.51 1.75 20.72 15.88 1.79
100 14.99 14.00 1.52 16.07 14.91 1.67 17.14 15.47 1.71 17.77 14.81 1.70 19.28 15.17 1.75 20.35 15.55 1.79
105 14.62 13.61 1.59 15.69 14.53 1.70 16.76 15.09 1.72 17.54 14.58 1.73 18.90 14.84 1.75 19.97 15.23 1.79
110 14.24 13.14 1.54 15.32 14.06 1.61 16.39 14.63 1.60 17.16 14.15 1.59 18.53 14.42 1.61 19.60 14.81 1.65
115 13.87 12.75 1.39 14.94 13.66 1.40 16.01 14.24 1.37 16.79 13.79 1.34 18.15 14.08 1.35 19.22 14.47 1.39
118 13.10 12.15 1.23 14.13 13.04 1.21 15.16 13.60 1.15 15.90 13.17 1.13 17.21 13.47 1.13 18.24 13.85 1.15
122 12.84 11.95 1.18 13.86 12.83 1.14 14.87 13.38 1.09 15.60 12.97 1.05 16.90 13.26 1.05 17.91 13.64 1.08
Heating Capacity Table
Model
(Btu/h)
Outdoor Air
Temp. ( °F DB )
Indoor Air Temp. °F DB / °F WB
°F DB °F WB
61 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
18K
0 -0.4 8.91 1.21 8.39 1.26 8.39 1.28 8.20 1.29 8.04 1.30 7.70 1.35
5 4.5 10.43 1.23 9.94 1.28 9.79 1.31 9.59 1.32 9.42 1.33 9.04 1.38
10 9 11.44 1.25 10.98 1.29 10.73 1.33 10.52 1.34 10.34 1.36 9.93 1.40
17 15 12.56 1.27 12.12 1.31 11.77 1.36 11.54 1.38 11.36 1.40 10.92 1.43
20 19 13.23 1.29 12.81 1.33 12.40 1.38 12.16 1.40 11.97 1.42 11.51 1.46
25 23 14.36 1.32 13.93 1.36 13.45 1.41 13.19 1.43 12.99 1.46 12.50 1.50
30 28 15.50 1.36 15.01 1.40 14.50 1.44 14.23 1.47 14.02 1.50 13.50 1.53
35 32 16.62 1.39 16.09 1.44 15.55 1.48 15.27 1.51 15.04 1.53 14.50 1.58
40 36 17.47 1.43 16.98 1.48 16.44 1.52 16.15 1.56 15.93 1.58 15.35 1.62
45 41 18.53 1.48 18.09 1.53 17.55 1.58 17.26 1.61 17.03 1.63 16.41 1.68
47 43 18.95 1.50 18.53 1.55 18.00 1.60 17.70 1.63 17.47 1.65 16.83 1.70
50 46 19.01 1.49 18.62 1.53 18.16 1.58 17.90 1.61 17.69 1.62 17.10 1.67
55 51 19.10 1.48 18.79 1.51 18.44 1.55 18.22 1.56 18.06 1.58 17.52 1.61
60 56 19.19 1.46 18.94 1.48 18.71 1.51 18.55 1.53 18.42 1.53 17.95 1.56
63 59 19.25 1.45 19.04 1.47 18.87 1.50 18.75 1.51 18.64 1.51 18.21 1.53
68 64 19.30 1.44 19.13 1.46 19.04 1.48 18.94 1.48 18.87 1.48 18.47 1.50
Remarks:
TC: Total Cooling Capacity (Gross)
SHC: Sensible Heat Capacity (Gross) PI: Power Input (including the compressor, evap. fan motor & cond. fan motor)
DB: Dry Bulb Temperature
WB: Wet Bulb Temperature
4
Capacities and selection data
SPECIFICATIONS
Capacity Characteristics Chart
Single Zone Ducted
Figure 213
