Friedrich FPWC1 - Product Dimensions: 18-36 K Cassette

16 PB
SPECIFICATIONS
Product Dimensions: 18-36k Cassette
9-3/4(248)
33-1/16(840)
37- 3/8(950)
(490 )
(478 )
(520 )
37-3/8(950)
33-7/8~35-13/16(860~910)
29-7/8(760)
)29-7/8(760
33-7/8~35-13/16(860~910)
33-1/8(841)
5 (127)
4-1/32(102)
4-5/16
(110)
7-1/8
(180)
5-1/8
(130)
(45 )
4-5/8 (118)
4-1/32 (102)
Unit: Inches “ (mm)
Figure 206
