Friedrich FPWC1 Service & Parts Manual

148 PB
PARTS CATALOG
12K Outdoor Condensor
Figure 902
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 67401110 1847918 - Fan Guard FPHFR12A3A 1
2 67401111 2103279 - Panel FPHFR12A3A 1
3 67401112 1203994 - Hex Nuts FPHFR12A3A 1
4 67400181 1556766 - Propeller Fan Blade FPHFR12A3A 1
5 67401113 1932167 - DC Motor FPHFR12A3A 1
6 67401114 2009048 - Motor Supporter FPHFR12A3A 1
7 67401017 1834430 - Connecting Board FPHFR12A3A 1
8 67401116 1972348 - Upper Board FPHFR12A3A 1
9 67401117 1926335 - Back Guard FPHFR12A3A 1
10 67401118 1570578 - Clapboard FPHFR12A3A 1
11 67400283 1829624 - PFC Inductance FPHFR12A3A 1
12 67401119 1971738 - Right Side Board FPHFR12A3A 1
13 67401120 1863156 - Wiring Distribution
Cover
FPHFR12A3A 1
14 67401121 1825563 - Valve Cover FPHFR12A3A 1
15 67400211 1546721 - Sensor Mounting
Plate
FPHFR12A3A 1
16 67401143 1973572 - Condenser FPHFR12A3A 1
17 67401144 2081826 - Four-way Valve FPHFR12A3A 1
18 67400193 1511783 - Four-way Valve Coil FPHFR12A3A 1
19 67401124 1841376 - Inverter Compressor FPHFR12A3A 1
20 67400396 1848625 - Electronic Expansion
Valve Coil
FPHFR12A3A 1
21 67401145 2107067 - Electronic Expansion
Valve
FPHFR12A3A 1
22 67401127 1555574 - Stop Valve FPHFR12A3A 1
23 67401128 1836723 - Inner Noise-
insulation Cotton
FPHFR12A3A 1
24 67401129 1566098 - Outer Noise-
insulation Cotton
FPHFR12A3A 1
25 67401130 1881249 - Bottom Noise-
insulation Cotton
FPHFR12A3A 1
26 67401131 1961881 - Base Holder FPHFR12A3A 1
27 67401132 1854766 ‑ Tube Electric Heater FPHFR12A3A 1
28 67401133 1805723 ‑ Fixing Clip
FPHFR12A3A
1
29 67401134 1926233 ‑ Electric Heating Belt
FPHFR12A3A
1
30 67401135 1226723 ‑ Compressor Hex Nuts
FPHFR12A3A
1
31 67401136 1899954 ‑ Electric Box Cover
FPHFR12A3A
1
32 67401146 2089130 ‑ Outdoor Main Control
Board Component
FPHFR12A3A
1
