153 PB
PARTS CATALOG
18K Outdoor Condensor
ITEM PART NUMBER PART DESCRIPTION USED ON MODEL QTY
1 67401011 1844024 ‑ Fan Guard FPHFR18A3A 1
2 67401012 2091948 ‑ Panel FPHFR18A3A 1
3 67401013 1263647 ‑ Hex Nuts FPHFR18A3A 1
4 67401014 1559520 ‑ Propeller Fan Blade FPHFR18A3A 1
5 67401015 1803035 ‑ Axis Sheath FPHFR18A3A 1
6 67400296 1859837 ‑ DC Motor FPHFR18A3A 1
7 67401016 1963835 ‑ Motor Supporter FPHFR18A3A 1
8 67401017 1834430 ‑ Connecting Board FPHFR18A3A 1
9 67401147 1972357 ‑ Upper Board FPHFR18A3A 1
10 67401019 1929744 ‑ Back Guard FPHFR18A3A 1
11 67401148 1972622 ‑ Clapboard FPHFR18A3A 1
12 67400268 1302261 ‑ PFC Inductance FPHFR18A3A 1
13 67401149 1971724 ‑ Right Side Board FPHFR18A3A 1
14 67401120 1863156 ‑ Wiring Distribution
Cover
FPHFR18A3A 1
15 67401121 1825563 ‑ Valve Cover FPHFR18A3A 1
16 67400211 1546721 ‑ Sensor Mounting Plate FPHFR18A3A 1
17 67401150 1993892 ‑ Condenser FPHFR18A3A 1
17.5 67401165 2089087 ‑ 4‑way valve assembly
ITEMS 18‑22
FPHFR18A3A 1
18 67401151 2089009 ‑ D tube assembly FPHFR18A3A 1
19 67401152 2089005 ‑ valve assembly FPHFR18A3A 1
20 67400457 1258444 ‑ 4‑way valve FPHFR18A3A 1
21 67401153 2089022 ‑ S tube assembly FPHFR18A3A 1
22 67401154 1995553 ‑ C tube FPHFR18A3A 1
23 67400193 1511783 ‑ Four‑way Valve Coil FPHFR18A3A 1
24 67401166 1834267 ‑ Inverter Compressor FPHFR18A3A 1
25 67400396 1848625 ‑ Electronic Expansion
Valve Coil
FPHFR18A3A 1
26 67401155 2089001 ‑ Electronic Expansion
Valve
FPHFR18A3A 1
27 67401156 1566329 ‑ Noise‑insulation Cotton FPHFR18A3A 1
28 67401157 1556828 ‑ Noise‑insulation Cotton FPHFR18A3A 1
29 67401158 1556825 ‑ Noise‑insulation Cotton FPHFR18A3A 1
30 67401159 2087547 ‑ Base Holder FPHFR18A3A 1
31 67401160 1876827 ‑ Electric Heating Belt FPHFR18A3A 1
32 67401135 1226723 ‑ Hex Nuts FPHFR18A3A 1
33 67401161 1987100 ‑ Electric Box Cover FPHFR18A3A 1
34 67401162 2086379 ‑ Outdoor Main Control
Board Component
FPHFR18A3A 1
Figure 903
To Next Page
