158 PB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 67400388 2010128 ‑ Fan Guard FPHFR24A3A 1
2 67400336 1382485 ‑ front panel FPHFR24A3A 1
3 67400337 1469450 ‑ Left guard filter FPHFR24A3A 1
4 67400998 1382782 ‑ mounting plate FPHFR24A3A 1
5 67400999 1231108 ‑ Welding hex nuts FPHFR24A3A 1
6 67400340 1899961 ‑ propeller fan FPHFR24A3A 1
7 67400341 1421124 ‑ FAN MOTOR FPHFR24A3A 1
8 67401091 1880176 ‑ motor supporter assy FPHFR24A3A 1
9 67400343 1908421 ‑ upper cover FPHFR24A3A 1
10 67400344 1469447 ‑ back guard filter FPHFR24A3A 1
11 67401092 1493224 ‑ side panel parts FPHFR24A3A 1
12 67400268 1302261 ‑ PFC inductance FPHFR24A3A 1
13 67401093 1536443 ‑ separate plate assy FPHFR24A3A 1
14 67401051 1472878 ‑ valve cover FPHFR24A3A 1
15 67400211 1546721 ‑ sensor mounting plate FPHFR24A3A 1
16 67401007 1202703 ‑ Handle FPHFR24A3A 1
17 67400921 2012524 ‑ baffle FPHFR24A3A 1
17.5 67401109 2009069 ‑ 4‑way valve assembly
ITEMS 18‑22
FPHFR24A3A 1
18 67400922 1993788 ‑ fixed board FPHFR24A3A 1
19 67400351 1993517 ‑ Tube electric heater FPHFR24A3A 1
20 67401094 2023540 ‑ Terminal Board FPHFR24A3A 1
21 67401095 2017892 ‑ Handle FPHFR24A3A 1
22 67401096 1225658 ‑ Four‑way Valve FPHFR24A3A 1
23 67401097 2019842 ‑ D tube assembly FPHFR24A3A 1
24 67401098 2019886 ‑ S tube assembly FPHFR24A3A 1
25 67401064 1302932 ‑ Four‑way Valve Coil FPHFR24A3A 1
26 67401099 1933256 ‑ condenser ASS'Y FPHFR24A3A 1
27 67400363 1993782 ‑ compressor FPHFR24A3A 1
28 67401100 1385852 ‑ Electronic Expansion
Valve Coil
FPHFR24A3A 1
29 67401101 1458701 ‑ Electronic Expansion
Valve
FPHFR24A3A 1
30 67401102 1469359 ‑ 1/4 stop valveASS'Y FPHFR24A3A 1
31 67401103 1469377 ‑ 5/8 stop valveASS'Y FPHFR24A3A 1
32 67401058 2003631 ‑ Base Holder Part FPHFR24A3A 1
33 67400366 1391303 ‑ Crankcase Heater FPHFR24A3A 1
34 67400401 2025749 ‑ Noise‑Insulation Cotton FPHFR24A3A 1
35 67400399 2025799 ‑ Noise‑Insulation Cotton FPHFR24A3A 1
PARTS CATALOG
24K Outdoor Condensor
Figure 904
