Friedrich FPWC1 Service & Parts Manual

172 PB
PARTS CATALOG
36K Indoor Cassette
Figure 909
ITEM PART NUMBER PART DESCRIPTION USED ON MODEL QTY
1 67400872 1913587 ‑ Base FPHFC36A3A 1
2 67400984 1416128 ‑ Air Duct Plate FPHFC36A3A 1
3 67401175 1416353 ‑ Fan Motor FPHFC36A3A 1
4 67401176 1509689 ‑ Side Panel FPHFC36A3A 1
5 67401177 1510203 ‑ Fan Snail Shell FPHFC36A3A 1
6 67400439 1514478 ‑ Pump Motor FPHFC36A3A 1
7 67400987 1515344 ‑ Cover FPHFC36A3A 1
8 67400440 1515168 ‑ Drainage Hose FPHFC36A3A 1
9 67400441 1416022 ‑ Centrifugal Fan FPHFC36A3A 1
10 67401178 1415926 ‑ Water Collecting Box FPHFC36A3A 1
11 67401179 1416069 ‑ Mounting Plate FPHFC36A3A 1
12 67400865 2014260 ‑ Elec Joint Box FPHFC36A3A 1
13 67400989 1415950 ‑ Elec Joint Box Cover FPHFC36A3A 1
14 67400365 1993154 ‑ Terminal Panel FPHFC36A3A 1
15 67401180 2108565 ‑ Indoor Main Control
Board Component
FPHFC36A3A 1
16 67400990 1462582 ‑ Cross Recessed Cheese
Head Screws
FPHFC36A3A 1
17 67400444 1413278 ‑ Coil Temperature
Sensor℃white℃
FPHFC36A3A 1
18 67401181 1416488 ‑ Mounting Plate FPHFC36A3A 1
19 67401182 2035334 ‑ Evaporator FPHFC36A3A 1
20 67401183 1509680 ‑ Side Panel FPHFC36A3A 1
21 67400993 1515050 ‑ Connecting Plate FPHFC36A3A 1
22 67401184 1509692 ‑ Side Panel FPHFC36A3A 1
23 67400446 1428008 ‑ Ambient Temperature
Sensor℃red℃
FPHFC36A3A 1
24 67400447 1362154 ‑ Water Level Switch FPHFC36A3A 1
‑25 67401169 2081569 ‑ Communication converter
board assembly ℃WIFI Module℃
FPHFC36A3A 1
‑26 67401168 4115759 ‑ Remote Controller FPHFC36A3A 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 2‑3 WEEKS LEAD TIME
