188 PB
PARTS CATALOG
36k Ducted Indoor
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 67401075 1506706 ‑ Base Plate FPHFD36A3A 1
2 67401076 1506966 ‑ Top Plate FPHFD36A3A 1
3 67401077 1506775 ‑ Mounting Plate FPHFD36A3A 1
4 67401078 1506769 ‑ Mounting Plate FPHFD36A3A 1
5 67401079 1401329 ‑ Water Drain FPHFD36A3A 1
6 67400955 1360977 ‑ Rubber Plug FPHFD36A3A 1
7 #N/A #N/A FPHFD36A3A 1
8 67401080 1506827 ‑ Float Bracket FPHFD36A3A 1
9 67400447 1362154 ‑ Water Position Switch FPHFD36A3A 1
10 67401082 1506878 ‑ Air Outlet FPHFD36A3A 1
11 67401081 1822423 ‑ Pump Supporting Bracket FPHFD36A3A 1
12 67400961 1368850 ‑ Tie‑in FPHFD36A3A 1
13 67400962 1368846 ‑ Water Pipe FPHFD36A3A 1
14 67400433 1397768 ‑ Pump Motor FPHFD36A3A 1
15 67400963 2080728 ‑ Electric Box Cover FPHFD36A3A 1
16 67401082 1506878 ‑ Air Inlet FPHFD36A3A 1
17 67400444 1413278 ‑ Coil Temperature Sensor FPHFD36A3A 1
18 67400323 1473879 ‑ Ambient Temperature
Sensor
FPHFD36A3A 1
19 67401083 1892226 ‑ Evaporator assembly FPHFD36A3A 1
20 67401084 1506712 ‑ Clapboard FPHFD36A3A 1
21 67401085 1849379 ‑ Motor Supporter FPHFD36A3A 1
22 67401086 1388001 ‑ Centrifugal Fan Blade FPHFD36A3A 1
23 67401087 1851355 ‑ Center Staff FPHFD36A3A 1
24 67400897 1537915 ‑ Hooking FPHFD36A3A 1
25 67400911 1537916 ‑ Hooking FPHFD36A3A 1
26 67401088 1852171 ‑ DC Motor FPHFD36A3A 1
27 67401089 1901093 ‑ Fan Snail Shell FPHFD36A3A 1
28 67400974 1484990 ‑ Electric Box FPHFD36A3A 1
29 67400429 1204016 ‑ Supporting Leg FPHFD36A3A 1
30 67400365 1993154 ‑ Wire Terminal Board FPHFD36A3A 1
31 67401090 2081219 ‑ Main Control Board FPHFD36A3A 1
‑32 67400997 4116375 ‑ Wire control components FPHFD36A3A 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 2‑3 WEEKS LEAD TIME
Figure 913D
