Friedrich FPWC1 - Page 48

48 PB
SPECIFICATIONS
Refrigerant Cycle 36k Outdoor Units
E
S C
D
1
2
6
9
Cooling cycle
Heating cycle
3
7
1
Compressor
2
Discharge temperature sennor
3
4
Suction temperature sennor
5
4-Way valve
6
Outdoor heat excharge
7
Coil temperature sennor
Ambient temperature sennor
9
10
Stop valve
Electronic expansion valv e
Stop valve
8
HP
LP
11
12
11
12
High pressure switch
Low pressure switch
S S
13
13
Strainer
5
4
10
8
Figure 234
