20
Table: Display console detailed items
5.4.1 Initial Display Console Set Up
Immediately after power up (inserting power adapter), the unit will turn on the
display, and the unit will start to look for reception of the indoor and outdoor
sensor data. This may take up to 3 minutes.
4 RF signal bar for PM2.5
sensor(optional sensor)
17 Multi-channel temperature and
humidity sensor cycle display
mode icon(optional sensor)
5 Sunrise / Sunset Time 18 Multi-channel temperature and
humidity sensor channel
number (optional sensor)
6 Wi-Fi signal bar 19 Rain fall
Daily/Event/Hourly/Weekly/
Monthly/Yearly
7 Low battery power indicator for
each sensor
20 RF signal bar for Rain fall
sensor(optional sensor)
8 RF signal bar for outdoor sensor
array
21 Weather forecast
9 Wind direction/Wind speed/Gust 22 ABS/REL Barometer
10 Water Leak Alarm (optional
Sensor)
23 Moon Phase
11 Indoor temperature 24 UV
12 Date and time 25 Solar Radiation
13 Soil moisture(optional sensor)
