Clean heat exchanger and flue gas collection chamber [~2500 Bh/yearly]
❒ Remove the insulating cover and thermal insulation
T4e 20-60:
❒
Loosen the lock nuts on both star-shaped screw knobs
➥ Use the spanner provided
❒ Unlock the cover by turning the star-shaped screw knob and remove
T4e 80-350:
❒ Connect the extension cable to the broadband probe
❒ Remove the spring bolt and lift the cover
➥ Use the spanner provided
❒ Clean the entire flue gas collection chamber using an ash vacuum
❒ Clean the WOS springs using a cleaning brush on both sides of the inner panel
NOTICE! WOS springs do not have to be removed for cleaning!
5
Servicing the system
Maintenance work by the operator
58 Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com
