Safety
Safety Devices
Fröling Heizkessel- und Behälterbau Ges.m.b.H, Industriestraße 12, A-4710 Grieskirchen, Austria Page 13
Tel +43 (0) 7248 606-0 Fax +43 (0) 7248 606-600 info@froeling.com www.froeling.com B0190806
2
2.4 Safety Devices
1 STOP key In case of overheating, shut down the
boiler
 The pumps continue to run!
 Always end heating with the
STOP key. Never use the main
switch.
2 Key switch (for screw
discharge)
Disengages power from the combustion
unit’s drive components.
 CAUTION: The power is still on
in the pellet module!
3 Main switch For shutting down the entire system
 The power to all components is
switched off.
 CAUTION: The power is still on
in the pellet module!
4 Safety temperature limiter
(STL)
 Page 14, Devices for preventing the
boiler from overheating
5 Fuse Fuse the controls and electrical
components
 When changing fuses, fit fuses with
the rated current specified.
2
4
1
3 5
