Fromm P329 M - ELECTRIC SCHEMATIC ELS.1082

PAGE 14 OF 26 0118 I H -7184
14
P329 M_HA mane.fm
7 CHART OF TYPES P329 M/HA
8 ELECTRIC SCHEMATIC ELS.1082
Item No. Model Strap width Strap thickness
43.2522 P329/16/0.65-1.05 16 mm / 5/8" 0.65-1.05 mm / .026 - .041"
43.2532 P329/19/0.65-1.05 19 mm / 3/4" 0.65-1.05 mm / .026 - .041"
43.2533 P329/19/1.06-1.35 19 mm / 3/4" 1.06-1.35 mm / .042 - .053"
18VDC
red
-
+
red
2
1
UB
M3
2
1
3
red
blue
1
2
(-)
(+)
M2
U
V
W
yellow
violett
brown
Hall3
Hall2
Hall1
GND
+5V
5
4
3
2
1
M1
2
1black
red
(+)
(-)
optional Fan
blackblack
black
DC
DP
2
1
HA
M
Manual / 1/2 Auto
