4.5 Suspension
When working stationary the P329 can be suspended at a spring loaded balancer by using a suspension
bracket. With the swivel mounted suspension bracket the package can be strapped in various working
positions.
The complete suspension bracket can be ordered under item number P32.0223.
4.6 Turning button kit
For a remaining adjustment of tension force and welding time.
After exchanging of the turning buttons the adjustment can only be changed with the allen key (2mm) that
comes with the kit. The kit can be ordered under the item number P32.2061.
P32.0223
N2.5623
P35.2073
P32.8302
P35.2069
N1.2163
Mobilux EP2
P32.8301
