PAGE 26 OF 26 0118 I H -7184
[ ] = Group * = Wearing parts
26
43253301.een.fm
P32.8138 P32.0211 1 CONICAL GEAR WHEEL D22
P32.8139 P32.0212 1 GEAR WHEEL D21
P32.8140 P32.0219 1 RETAINER A22
P32.8141 P32.0219 1 COVERING B21
P32.8142 P32.0219 1 HANDLE LEVER B21
P32.8150 P32.0219 1 TOUCH CONTACT-SWITCH A21
P32.8153 P32.0214 1 GEAR WHEEL B24
P32.8157 P32.0218 1 BODY C7
P32.8158 P32.0221 1 COVER A4
P32.8159 P32.0222 1 END COVER C5
P32.8169 1 STRAP STOP B1
P32.8178 1 STRAP GUIDE D4
P32.8195 1 COVER C9
[P32.8199] P32.0229 1 CIRCUIT BOARD B20
[P33.0204] P32.0219 1 GEAR WHEEL B18
P33.2115 P32.8199 1 TURNING BUTTON C20
P33.2145 P32.0219 1 DISK B21
P33.2155 P32.0219 1 DOWEL C22
[P35.0146] 1 PUSHER C12
P35.3104 P32.0205 3 IDLER GEAR C13
P35.3201 3 IDLER GEAR B4
P35.3203
*
1 TENSIONING WHEEL C4
P35.3214
*
1 CUTTER C11
P35.3215 1 GUIDE CASE B11
P35.3218 1 GUIDE PIN D12
P35.3219 1 GUIDE PIN D12
P35.3220 1 SEESAW LEVER B11
P35.3221 1 SEESAW LEVER C12
P35.3223 P35.0146 1 THRUST PIECE B12
43.2533.01 P329/19/1.06-1.35 P329.0001.01 13.05.14
Item-No. in group Pcs. Description Dimension Field
