Fronius MagicWave 5000 User Manual

105
EN
TransTig
2500 / 3000 MV
Weight 24.2 kg
53.35 lb.
24.2 kg
53.35 lb.
Mark of conformity S, CE S, CE
TT 2500 TT 3000
TT 2500 MV TT 3000 MV
Mains voltage 3 x 200 - 240 V
3 x 400 - 460 V
1 x 200 - 240 V
3 x 200 - 240 V
3 x 400 - 460 V
1 x 200 - 240 V
Mains voltage tolerance ± 10 % ± 10 %
Mains frequency 50/60 Hz 50/60 Hz
Mains fuse protection (slow-blow)
3 x 400 - 460 V
3 x 200 - 240 V
1 x 200 - 240 V
16 A
32 A
32 A
16 A
32 A
32 A
Mains connection
1)
Z
max
at PCC
3)
= 172 mOhm
Z
max
at PCC
3)
= 97 mOhm
Primary continuous power (100% d.c.
2)
)
3 x 400 - 460 V
3 x 200 - 240 V
1 x 200 - 240 V
4.7 kVA
4.1 kVA
4.3 kVA
5.9 kVA
5.0 kVA
4.3 kVA
Cos phi 0,99 0,99
Welding current range (3-phase)
TIG 3 - 250 A 3 - 300 A
Electrode 10 - 250 A 10 - 300 A
Welding current range (single phase)
TIG 3 - 220 A 3 - 220 A
Electrode 10 - 180 A 10 - 180 A
Welding current at 3 x 400 - 460 V
10 min/40 °C (104 °F) 45% d.c.
2)
- 300 A
10 min/40 °C (104 °F) 50% d.c.
2)
250 A -
10 min/40 °C (104 °F) 100% d.c.
2)
200 A 240 A
Welding current at 3 x 200 - 240 V
10 min/40 °C (104 °F) 35% d.c.
2)
--
10 min/40 °C (104 °F) 40% d.c.
2)
250 A 300 A
10 min/40 °C (104 °F) 100% d.c.
2)
180 A 210 A
Welding current at 1 x 200 - 240 V
10 min/40 °C (104 °F) 50% d.c.
2)
220 A -
10 min/40 °C (104 °F) 55% d.c.
2)
- 220 A
10 min/40 °C (104 °F) 100% d.c.
2)
190 A 190 A
Open circuit voltage 85 V 85 V
Working voltage
TIG 10.1 - 20.0 V 10.1 - 22.0 V
Electrode 20.4 - 30.0 V 20.4 - 32.0 V
Striking voltage (U
p
) 10 kV 10 kV
The arc striking voltage is suitable for manual operation.
