12
General information
Device concept The single-phase battery charging systems for 24 V and 48 V batteries are fitted with intel-
ligent charging technology. The successful Active Inverter Technology with the revolution-
ary Ri charging process adapts itself to the requirements of the battery and only charges
the battery with the current that it actually needs.
The technology is embedded in a robust industry-standard housing. The exceptionally
compact design complies with all safety standards, requires less installation space and
protects the components to ensure a long service life.
Fitted with a graphical display, an integrated datalogger, new interfaces and additional op-
tions, the device is perfectly equipped for the future.
Proper use
WARNING!
Danger due to unsuitable batteries being connected to the charger.
This can result in serious injury and damage to property due to escaping gas, fire or explo-
sion.
► Never connect a battery to the charger unless it is compatible in terms of its type, volt-
age and capacity and corresponds to the charger settings.
The battery charging system is only suitable for charging the following batteries:
Power cate-
gory
Cell type Minimum
number of
cells
Maximum
number of
cells
Minimum
nominal ca-
pacity [Ah]
Maximum
nominal ca-
pacity [Ah]
Selectiva
2040 2 kW
Pb-Wet/GEL 1 12 10 800
NiCd 2 20 10 800
Selectiva
2050 2 kW
Pb-Wet/GEL 1 12 10 1000
NiCd 2 20 10 1000
Selectiva
2060 2 kW
Pb-Wet/GEL 1 12 10 1200
NiCd 2 20 10 1200
Selectiva
2070 2 kW
Pb-Wet/GEL 1 12 10 1400
NiCd 2 20 10 1400
Selectiva
4020 2 kW
Pb-Wet/GEL 1 24 10 400
NiCd 2 40 10 400
Selectiva
4035 2 kW
Pb-Wet/GEL 1 24 10 700
NiCd 2 40 10 700
Selectiva
2080 3 kW
Pb-Wet/GEL 1 12 20 1600
NiCd 2 20 20 1600
Selectiva
2100 3 kW
Pb-Wet/GEL 1 12 20 2000
NiCd 2 20 20 2000
Selectiva
2120 3 kW
Pb-Wet/GEL 1 12 20 2000
NiCd 2 20 20 2000
Selectiva
4045 3 kW
Pb-Wet/GEL 1 24 20 900
NiCd 2 40 20 900
