Fronius Symo Advanced Series User Manual

36
1 2
3 4
5 6
1
2
1
DC+
DC-
2
DC =
DC =
1
D1
D2
D3
D1
D1
D1
0.59 in.
(15 mm)
2.76 in.(70 mm)
> AWG 10
(6 mm²)
AWG 14 ... AWG 6 copper direct
AWG 6 aluminum direct
AWG 4 copper or aluminum with
input combiner
2
6-21 mm² / 10-4 AWG / Al/Cu
5.5 Nm / 48.6 lbf.in
option
DC+
DC-
42,0201,4479
42,0201,4479
42,0201,4480
42,0201,4480
10.0-3, 12.0-3 208-240 max. 41,5 A
15.0-3, 20.0-3, 22.7-3, 24.0-3 480 max 51 A
12x 1.8 Nm / 16 lbf.in
BASIC
MPP TRACKER 2
OFF
3
Torque (Nm / lbf.in.)
→ see printing near wire terminal
4
1
2
1
DC = (+)DC = (-)
2
DC =
5
10.0-3 - 12.0-3 208-240
U
DC max
0 - 11154 ft.
(0 - 3400 m)
ft. (m)
600 V
1000 V
0 - 6561 ft.
(0 - 2000 m)
> 8202 - 9842 ft.
(> 2500 - 3000 m)
> 6561 - 8202 ft.
(> 2000 - 2500 m)
> 9842 - 11154 ft.
(> 3000 - 3400 m)
950 V
900 V
850 V
U
DC max
ft. (m)
10.0-3 - 24.0-3 480
6

Fronius Symo Advanced Series Specifications

General

Smart Grid Ready	Yes
Protection Rating	IP66
MPP voltage range	200 - 800 V
Number of MPP trackers	2
Frequency	50/60 Hz
Operating Temperature Range	-25°C to +60°C
Integrated Data Communication	Yes
AC nominal voltage	230 V / 400 V
Output Voltage	230 V / 400 V
Warranty	5 years
