Service paramet-
ers
Various service parameters can be retrieved by pressing the "Parameter selection" but-
tons at the same time.
Opening the display
1
The first parameter "Firmware version" will
be displayed, e.g., "1.00 | 4.21"
Selecting parameters
2
Use the "Mode" and "Process" buttons or
the left-hand selection dial to select the
required setup parameter
Available parameters
Explanation
Example:
1.00 | 4.21
Firmware version
Example:
2 | 491
Welding program configuration
Example:
r 2 | 290
Number of the currently selected welding
program
Example:
654 | 32.1
= 65,432.1 hours
= 65,432 hours 6 mins
Indicates the actual arc time since first
use
Note: The arc time indicator is not suitable
as a basis for calculating hiring fees or for
warranty purposes, etc.
Example:
iFd | 0.0
Motor current for wire drive in A
The value changes as soon as the motor
is running.
2nd 2. menu level for service technicians
35
