Keylock A keylock can be selected to prevent the settings from being inadvertently changed on
the control panel. As long as the keylock is active:
- Settings cannot be adjusted on the control panel
- Only parameter settings can be retrieved
- Any assigned "Save" button can be retrieved provided that an assigned "Save" but-
ton was selected when the keylock was enabled
Activating/deactivating the keylock:
1
Keylock activated:
The message "CLO | SEd" appears on the
displays.
Keylock deactivated:
The message "OP | En" appears on the
displays.
The keylock can also be activated and deactivated using the keylock switch option.
36
