Frontier ST7526 - Hazard Symbols and Their Meanings; Operating Symbols and Their Meanings

A signal word (DANGER, WARNING, or CAUTION) is used with the alert
symbol to indicate the likelihood and the potential severity of injury. In
addition, a hazard symbol may be used to represent the type of hazard.
DANGER indicates a hazard which, if not avoided, will result in
death or serious injury.
WARNING indicates a hazard which, if not avoided, could result in
death or serious injury.
CAUTION indicates a hazard which, if not avoided, might result in
minor or moderate injury.
CAUTION, when used without the alert symbol, indicates a
situation that could result in damage to the equipment.
Hazard Symbols and their Meanings
These symbols are used on your equipment and defined in your operating
manual. Review and understand the meanings. The use of one of these
symbols combined with a signal word will alert you to potential hazards
and how to avoid them.
Operating Symbols and their Meanings
These symbols are used on your equipment and defined in your operating
manual. It is important that you review and understand the meanings.
Failure to understand the symbols might result in harm to you.
RULES FOR SAFE OPERATION
3
This manual contains safety information to make you
aware of the hazards and risks associated with
snowthrowers, and how to avoid them. The snowthrower is designed
and intended for removal of snow, and should not be used for any other
purpose. It is important that you read and understand these
instructions, and anyone operating the equipment read and understand
these instructions.
WARNING
The engine exhaust from this product contains chemicals known to the
State of California to cause cancer, birth defects, or other reproductive
harm.
Safety Alert – Identifies safety information about hazards
that can result in personal injury.
Operator’s Manual – Read and understand before
performing any activity or running equipment.
Rotating auger Fire
Rotating impeller Explosion
Toxic fumes Shock
Rotating gears Hot surface
Thrown objects
Never reach into
rotating parts.
Keep a safe distance
from the equipment.
Recommended ear
protection for extended
use.
Shut off engine and remove spark plug connector before
performing maintenance or repair work.
Oil
Fuel Forward
On Off Neutral
Primer bulb Reverse
Throttle
Choke off Ignition On
Choke on Ignition Off
Stop Ignition Key
Slow
Push to engage
electric start
Fast Electric Start
Engage Engine Start
Traction Engine Run
Auger Collector Engine Off
Auger Clutch Engage
Drive Clutch Disengage
Heated Grips
Discharge Chute Chute Deflector
LEFT RIGHT UP DOWN
