TOOLS REQUIRED FOR ASSEMBLY
1 – Knife
2 – 1/2" wrenches (or adjustable wrenches)
2 – 9/16" wrenches (or adjustable wrenches)
2 – 3/4" wrenches (or adjustable wrenches)
1 – 3/8" wrenches (or adjustable wrenches)
1 – Pair pliers or screw driver (to spread cotter pin)
CONTENTS OF SHIPPING CARTON
1 – Snowthrower
1 – Container of Fuel Stabilizer (Located in Parts Bag)
1 – Snow Chute Assembly
1 – Crank Assembly
1 – Parts Bag
WARNING: Always wear safety glasses or eye shields
while assembling snowthrower.
HOW TO MEASURE SCREW SIZE
DIAMETER
LENGTH
ASSEMBLY
9
PARTS BAGS CONTENTS:
* Non Assembly parts are found in toolbox located on top of belt cover.
*2 – Shear Bolt
*2 – Spacer
1 – Ignition Key
1 – Shift Lever Knob
(not actual size)
*2 – Nut
To Next Page
