Figure 36
Swing Plate Axle Rod
E-Ring
Engine Pulley
Traction Drive Pulley
Traction Drive Belt
Traction Drive Spring
Auger Drive Belt
Auger Drive Pulley
Belt Guide
Traction
Drive Belt
Engine Pulley
Traction Drive Idler Pulley
Idler Pulley
MAINTENANCE
30
