I/O Port Pin Out
Appendix E:
Pin-Out Guide
Pin #
Wire Color
Function
1
Orange
TX1
2
Brown
TX2
3
Red
RX1
4
White
RX2
5
Black
GND 1 (IR or GPI)
6
Y
ellow
GND 2 (Power)
7
Blue
IR Out+ or GPI
8
Green
12V or 9V
LAN RJ-45 Pin Out
Pin #
Function
1
TX+
2
TX-
3
RX+
4
GND_Ethernet power
5
GND_Ethernet power
6
RX-
7
+12_Ethernet power
8
+12_Ethernet power
