Frye FONIX 8000 - 8000 With 8120 Chamber System Block Diagram

16 Maintenance Manual
4.2.2 8000 with 8120 Chamber System Block Diagram
8000 Circuit Description
2010-10-27
Page 1 of 14
8000 with Probe and 8120 Chamber System Block Diagram:
Probe Module Main Module
SBC
Daughter Board
Connector Board
8120 Chamber
Therm Printer
Inter Board
Therm Printer
Off Line PS
Voice Mic
Ext Keyboard
Main Keyboard
BreakOut Board
M1950E
Batt Pill
HiPro out
Probe Mic B
Headset
ER3
Probe Keyboard
SF Speaker B
Probe Mic A
2 Line inputs
(CD player)
Ethernet
USB
Host
(X2)
VGA
RS232
PC/104
Probe Board
Telewand
HiPro in
Turntable board
SF Speaker A
Par Int board
Step motor
LED
White LED
USB
Device
Chamber
Board
Speaker
Telecoil
