44 Maintenance Manual
Rear Panel Layout
Letters identify rear panel safety markings
FRYE
KEYBD
LINE
INPUT
MIC
INPUT
MODULE 1
RS232
COMPUTER
VGA
MODULE 2
ETH 0ETH 1
FONIX
®
8000
HEARING AID TEST SYSTEM
ELECTRONICS MODULE
ATTENTION: For service refer to qualified personnel
only. Consult accompanying documents.
ELECTRICAL RATING:
100–240 V
~
50-60 Hz .6A
FRYE
Made in Tigard, Oregon, USA
By Frye Electronics, Inc.
Frye Electronics products are protected by U.S.
and/or foreign patents and/or patents pending
T630 mAL
FONIX 8000 Serial No. 1234
