Frymaster 1814 Series Gas Fryers
Chapter 3: Installation
3-8
CE GAS CONVERSION INSTRUCTIONS
1. Between G20- and G25-type Natural Gas, adjust the gas pressure at the regulator. (Refer to the
CE Standard Burner Manifold Gas Pressure Chart.) Do not change the orifice.
2. Between a 2
nd
family (G20 or G25) and a 3
rd
family gas (G30 Butane or G31 Propane):
a. Change the orifices.
b. Adjust the manifold pressure.
3. Affix the new label included with the conversion kit next to the existing rating plate stating that
the gas type has been converted. Remove any references to the previously used gas from the
existing rating plate.
Conversions can only be executed by qualified, factory-authorized personnel.
Pressure flow adjustment
(remove cover screw to
access)
ON/OFF
Gas-Cock Knob
Pilot gas supply
connection.
Regulator Vent
Pilot pressure adjustment
(remove cover screw to
access)
Typical non-CE gas valve for electronic-ignition equipped fryers.
