HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-3
2.1.1 Decathlon HD50 Primary Components (includes SCFHD units) (cont.)
ITEM PART # COMPONENT
* 231-2060 Side Panel, Left Side (SCFHD50 C/C)
* 232-2060 Side Panel, Right Side (SCFHD50 C/C)
16 200-1674 Back Panel, Lower
* 200-3183 Back Panel (2-battery)
* 200-3567 Back Panel (3-battery)
17 823-5303 Wireway, Control Panel
18
►►► See Control Panel Options, Joiner Strips, and Accessories, Section 2.3
19 824-1103 Top Cap, Single
*
824-0937 Top Cap, Double
*
106-5955 Top Cap, Double (SCFHD50 C/C)
* 824-0983 Top Cap, Triple
20 106-3720 Flue Box Assembly
* 200-6269 Shield, Flue Heat
* 200-6268 Front, Flue Box
* 200-6270 Rear, Flue Box
21 823-3521 Flue Cap (Single)
* 823-3634 Flue Cap (Double)
* 106-6777 Flue Cap (Triple)
* 200-1682 Bracket, Flue Mounting
22 106-4727SP Door Assembly, Left
* 106-4728 Door Assembly, Right
* 210-8946 Panel, Outer Door, Left/Right
* 201-8945 Panel, Inner Door, Left
23 106-7542 Door Assembly (SCFHD50 C/C)
* 230-2256 Panel, Outer Door
* 220-2259 Panel, Inner Liner
24 810-0180 Handle, Door, Wireform
25
210-8077 Handle, Door, Common Cabinet
* 810-1105 Magnetic Catch, Door
* 803-0271 Basket, Twin
* 803-0099 Basket, Full
26 803-0277 Grid Assembly, Fine Mesh
27 210-1595 Hanger, Basket, Single System, (attaches to flue)
* 210-3131 Hanger, Basket, Double System (attaches to flue)
28 810-0356 Caster, Plate-mount, 5-inch without Brake
29 810-0357 Caster, Plate-mount, 5-inch with Brake
* 826-1117 Caster Kit (includes 810-0356 and hardware x1)
* 826-1118 Caster Kit (includes 810-0357 and hardware x1)
30 812-1226SP Drain Nipple, Extended 1¼” " Drain (Single)
* 812-1717SP Drain Nipple, Extended 1½” Drain
* 807-0154 Cordset, 10' Power
31 210-2804 Cover, Outlet Duct
32 810-2411 Leg, Single Bolt Mount (black)
* 810-3169 Leg Package, 4 Bolt Mount (4 per set)
33 823-3248 Leg Support Assembly
34 200-8895 Burner Mounting Rail
35 220-0891 Brace, Front Horizontal, Single (SCFD C/C)
* 220-0882 Brace, Front Horizontal, Double (SCFD C/C)
* Not illustrated.
