HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-4
2.1.2 Decathlon HD60 Primary Components (includes SCFHD units)
ITEM PART # COMPONENT
1 823-4692 Frypot - S/S (SCFHD)
* 823-5742 Frypot - S/S (Single HD without filtration)
* 106-7853 Frypot - S/S (SCFHD63)
* 823-6314 Frypot - S/S (Single HD63 without filtration)
2 810-2072 Gas Manifold (weld assembly; also used on HD63 fryers)
3
►►► See Orifices, Section 2.2
4
810-2032 Pilot Burner, Natural/G20/25 Gas
*
810-2155 Pilot Burner, LP/G31 Gas
*
106-1839SP Pilot Assembly, Natural Gas Electronic Ignition with Computer
*
106-1238SP Pilot Assembly, Natural Gas Electronic Ignition without Computer
* 810-0705
Tube, Pilot Gas Supply,
1
⁄
4
" x 23" (one-piece gasline)
* 810-0703
Tube, Pilot Gas Supply,
1
⁄
4
" x 17
1
⁄
2
" (one-piece gasline)
5 220-1231 Bracket, Manifold Support (right or left)
6 230-1431 Diffuser Assembly
7
►►►
See Drain Manifold Components, Section 2.5
8 810-2785 Burner, High Efficiency
9 200-1363 Heat Shield, Lower
* 200-8053 Heat Shield, Vessel
* 812-0211 Insulation, Kaowool Blanket, .5” x 7.5” x 17.5”
* 230-2057 Support, Burner
10 807-3552 Gas Valve, Natural Gas, Electronic Ignition, 24 VAC (
3
⁄
4
" in,
1
⁄
2
" out)
* 807-3628 Gas Valve, LP Gas, Electronic Ignition, 24 VAC
* 807-3294 Gas Valve, Natural Gas, Constant Pilot, 24 VAC
* 807-3295 Gas Valve, LP Gas, Constant Pilot, 24 VAC
*
807-2091
Gas Valve, G20/G25 Gas, 24 VAC (CE only)
*
807-2127
Gas Valve, G31 Gas, 24 VAC (CE only)
* 810-0691 Vent Tube
* 823-3347 Frame, Slide Base
11 220-2187 Channel, Rear and Front
* 200-3219 Channel, Base (Single and 3-battery)
* 200-1198 Channel, Base (2-, 3-, and 4-battery)
* 200-1463 Channel, Base (4-battery)
* 200-1393 Channel, Lower Joiner
* 823-5790 Channel, Base (Single, SCFHD60 C/C)
* 200-8095 Channel, Front Base (SCFHD60 C/C)
* 220-1339 Channel, Rear Base (3-battery, SCFHD60 C/C)
* 220-1362 Channel, Rear Base (4-battery, SCFHD60 C/C)
* 106-4424 Base Assembly (4-battery, SCFHD60 C/C)
* 106-5622 Base Assembly (3-battery, SCFHD60 C/C)
* 106-6643 Base Assembly, HD63
12 823-5346 Hinge, Lower Left
* 823-5347 Hinge, Lower Right
13 823-5348 Hinge, Upper Left
* 823-5349 Hinge, Upper Right
* 823-4894 Hinge, Lower Left (SCFHD50 C/C)
* 823-4895 Hinge, Lower Right (SCFHD50 C/C)
* 823-5136 Hinge, Upper Left (SCFHD50 C/C)
* 823-5137 Hinge, Upper Right (SCFHD50 C/C)
* Not illustrated.
